VC70B-PTH
In-vehicle System, Intel® Core™ Ultra Series 3 processors, LPDDR5x, OOB, 1 HDMI, 1 DP, 1 USB-C DP, 1 M.2 M Key, 1 M.2 B Key, 1 M.2 E Key, 2 2.5GbE, 1 GbE, 5 USB 3.2, 1 USB-C, 3 COM, 2 CAN FD, -20 to 70°C
- Ultra-compact, stylish, and AI-powered in-vehicle system for smart mobility
- Intel® Core™ Ultra Series 3 processors with LPDDR5x-8533 memory
- Remote Management: Supports Out of band control
- Build-in 9 axis sensor for driver detection within fleet management
- Triple Displays: 1 HDMI, 1 DP, 1 USB-C DP Alt. mode
- Multiple Expansion: 1x M.2 M Key, 1x M.2 B Key, 1x M.2 E Key
- Rich I/O: 2 2.5GbE, 1 GbE, 5 USB 3.2, 1 USB-C, 2 USB 2.0, 3 COM, 2 CAN FD
Főbb jellemzők
Tanúsítványok
#Windows 10
#9~36V DC-in
#USB Type-C DP
#M.2
#LPDDR5x
#E-Mark (E24) Certification
#Intel® Core™ Ultra Series 3 processors
#Out-Of-Band (OOB)
#IoT
#Windows 11
#Intel
#SIM Slot
#Compact PC
#Fanless Design
#Compact Size
#4K2K Display
#1G Ethernet
#Windows
#Linux
#HDMI
#DP
#Multiple Expansion
#RoHS Certification
#CE Certification
#FCC Certification
#In-Vehicle
#2.5G Ethernet
#UKCA Certification
Főbb jellemzőkKey features
- Ultra-compact, stylish, and AI-powered in-vehicle system for smart mobility
- Intel® Core™ Ultra Series 3 processors with LPDDR5x-8533 memory
- Remote Management: Supports Out of band control
- Build-in 9 axis sensor for driver detection within fleet management
- Triple Displays: 1 HDMI, 1 DP, 1 USB-C DP Alt. mode
- Multiple Expansion: 1x M.2 M Key, 1x M.2 B Key, 1x M.2 E Key
- Rich I/O: 2 2.5GbE, 1 GbE, 5 USB 3.2, 1 USB-C, 2 USB 2.0, 3 COM, 2 CAN FD
System
- Processor
- Intel® Core™ Ultra 7/5 Processors, TDP up to 28W Intel® Core™ Ultra 7 165H, 16C, 24M Cache, 1.4GHz~5.0GHz, 28W Intel® Core™ Ultra 7 155U, 12C, 12M Cache, 1.7GHz~4.8GHz, 15W Intel® Core™ Ultra 5 125U, 12C, 12M Cache, 1.3GHz~4.3GHz, 15W
- Memory
- Up to 64GB LPDDR5x memory down w/max. 8533
- BIOS
- AMI SPI 256Mbit
Graphics
- Controller
- Intel Arc Graphics
- Feature
- DX12, Open GL 4.6, Vulkan 1.2 HW Decode: HEVC/VP9/AV1/AVC/H.265/MJPEG HW Encode: HEVC/VP9/AV1/AVC/H.265/MJPEG
- Display
- 1 x HDMI 1.4b, Resolution up to 4096x2160@24Hz 1 x DP++, Resolution up to 4096x2160@24Hz 1 x USB-C DP Alt. mode, Resolution up to 4096x2304@60Hz
- Triple Displays
- HDMI + DP + USB-C DP Alt. mode
Expansion
- Interface
- 1 x M.2 M key 2280 (PCIe Gen4 x4) 1 x M.2 B key 3052 (USB 3.0/2.0, PCIe x1), 1 x SIM slot for 4G/5G 1 x M.2 E key 2230 (USB 2.0/PCIe x1)
Ethernet
- Controller
- 2 x Intel I226IT (10/100/1000/2500Mbps) 1 x Intel I210IT (10/100/1000Mbps)
LED
- Indicators
- 1 x Power LED 1 x HDD LED
Front I/O
- Ethernet
- 2 x 2.5GbE @ RJ45 connectors
- USB
- 5 x USB 3.2 Type A 1 x USB Type C 2 x USB 2.0 Type A
- Display
- 1 x HDMI 1 x USB-C DP Alt. Mode 1 x DP++
- SIM
- 1 x Nano SIM slot
Rear I/O
- Ethernet
- 1 x GbE @RJ-45 connector (support OOB)
- Serial
- COM 1: RS-232/422/485 COM 2: RS-232
- CANBus
- 2 x CAN FD (DB9-M)
- SD
- 1 x Micro SD slot for OOB
Watchdog Timer
- Output & Interval
- System Reset, Programmable via Software from 1 to 255 Seconds
Security
- TPM
- TPM 2.0
Power
- Type
- 9~36V DC
- Connector
- 3-pin terminal block (VCC/IGN/GND)
- RTC Battery
- CR2032 Coin Cell (Cable type)
- Power Management
- 1. Ignition On/Off control 2. System On delay time 3. OS Protection Time 4. System Off delay time 5. Car Battery Voltage Monitoring 6. Battery Low Voltage Protect
OS Support
- Microsoft
- Windows 11 & 10 IoT Enterprise 64-bit
- Linux
- Linux (by request)
Environment
- Temperature
- Operating: -20 to 70°C fanless Operating: -20 to 50°C fanless (28W CPU only) Storage: -40 to 85°C
- Humidity
- Operating: 5 to 95% RH Storage: 5 to 95% RH
Mechanism
- Dimensions
- 181.6mm (W) x 71.5mm (H) x 118.4mm (D)
- Mounting
- Wall mount
- Weight
- < 3KG
Standards and Certifications
- Shock
- Operating/non-operating: MIL-STD-810G Method 516.6, Procedure 1
- Vibration
- Operating/non-operating: MIL-STD-810G Method 514.6, Category 4
- Certifications
- CE, FCC Class A, E-Mark (E24), RoHS, UKCA
Country of Origin
- Country of Origin
- Taiwan
