PTH961
COM Express® Basic, Intel® Core™ Ultra Series 3 processors, LPDDR5, 8K/4K, 3 DDI, 1 LVDS/eDP, 20 PCIe, 1 Intel 2.5GbE, 2 USB 4.0, 4 USB 3.2, NVMe SSD
- UP to 64GB LPDDR5x- 8533 memory down
- 8K High Resolution: Supports 8K / 4K resolution
- Multiple Displays: 3 DDI, 1 LVDS/eDP
- Multiple Expansion: Up to 20 PCIe Lanes
- Rich I/O: 1 Intel 2.5GbE, 2 USB 4.0, 4 USB 3.2
Főbb jellemzők
Tanúsítványok
#8K resolution
#LVDS
#eDP
#SMBus
#I2C
#UART
#LPDDR5x
#Intel® Core™ Ultra processors
#IoT
#Intel
#4K2K Display
#Windows
#Linux
#Multiple Expansion
#RoHS Certification
#CE Certification
#FCC Certification
#2.5G Ethernet
Főbb jellemzőkKey features
- UP to 64GB LPDDR5x- 8533 memory down
- 8K High Resolution: Supports 8K / 4K resolution
- Multiple Displays: 3 DDI, 1 LVDS/eDP
- Multiple Expansion: Up to 20 PCIe Lanes
- Rich I/O: 1 Intel 2.5GbE, 2 USB 4.0, 4 USB 3.2
System
- Processor
- Intel® Core™ Ultra Series 3 Processor Panther Lake Intel® Core™ Ultra X7 358H (4 P-Cores x 1.9GHz, 8 E-Cores x 1.5GHz, 4 LP E-Cores x 1.5GHz, 18MB cache, 25W) Intel® Core™ Ultra 5 325 (4 P-Cores x 2.1GHz, 4 LP E-Cores x 1.6GHz, 18MB cache, 25W)
- Memory
- Up to 64GB (optional to 96GB) LPDDR5x-8533 memory down (IBECC supported)
- BIOS
- AMI BIOS
Graphics
- Controller
- Intel® Arc Graphics or Intel® Gr aphics
- Feature
- DX12, Open GL 4.6, Vulkan 1.2 HW Decode: HEVC/VP9/SCC/AV1/AVC HW Encode: HEVC/VP9/SCC/AVC
- Display
- 3 x DDI (DDI3 co lay with USB3) 1 x LVDS/eDP
Expansion
- Interface
- 404/12Xe sku: Up to 8 x PCIe x1 (Gen4) + 1 x PCIe x4 (Gen5) 484 sku: Up to 8 x PCIe x1 (Gen4) + 1 x PCIe x8 (Gen5) + 1 x PCIe x4 (Gen5) 1 x I2C 1 x SMBus 1 x eSPI 2 x UART
Audio
- Audio Codec
- HD Audio
Ethernet
- PHY
- 1 x Intel® I226 series (10/100/1000/2500Mbps), co-lay 1 x PCIe x1 (available upon request)
I/O
- USB
- Up to 2 x USB 4.0 (co-lay with DDI, available upon request) 4 x USB 3.2 Gen.2 8 x USB 2.0
- SATA
- 2 x SATA 3.0 (up to 6Gb/s), co-lay PCIe x1 (available upon request)
- DIO
- 1 x 8-bit DIO
- NVMe SSD
- 1 x 128GB/256GB/512GB/1024GB on board SSD (available upon request)
Watchdog Timer
- Output & Interval
- System Reset, Programmable via Software from 1 to 255 Seconds
Security
- TPM
- TPM 2.0
Power
- Type
- 8.5V~20V, 5VSB, VCC_RTC (ATX mode) 8.5V~20V, VCC_RTC (AT mode)
- Consumption
- TBD
OS Support
- Microsoft
- Windows 11 IoT Enterprise 64-bit
- Linux
- Linux
Environment
- Temperature
- Operating: -40 to 85°C for ET CPU skus, 0 to 60°C, Storage: -40 to 85°C
- Humidity
- Operating: 10 to 90% RH Storage: 10 to 90% RH
- MTBF
- TBD
Mechanism
- Dimensions
- COM Express® Basic 125mm (4.92") x 95mm (3.74")
- Compliance
- PICMG COM Express® R3.1, Type 6
Standards and Certifications
- Certifications
- CE, FCC, RoHS
Country of Origin
- Country of Origin
- Taiwan
