SNA9HE
COM HPC® Server Size E, AMD EPYC™ 8004 Processor, DDR5, Up to 79 PCIe Lanes, 1 Intel 2.5GbE, 4 USB 3.2, 4 USB 2.0, 2 SATA 3.0
- AMD EPYC 8004 Processor, up to 64 cores
- Up to 6 channels DDR5 4800 RDIMM
- 1 x Intel® I226 series 10/100/1000/2500Mbps GbE
- Multiple Expansion: Up to 79 PCIe Lanes
- Rich I/O: 4 USB 3.2, 4 USB 2.0, 2 SATA 3.0
Főbb jellemzők
Tanúsítványok
#DDR5
#SMBus
#I2C
#AMD EPYC™ 8004 processors
#PCIe x16
#Windows
#Linux
#Multiple Expansion
#RoHS Certification
#CE Certification
#FCC Certification
#2.5G Ethernet
Főbb jellemzőkKey features
- AMD EPYC 8004 Processor, up to 64 cores
- Up to 6 channels DDR5 4800 RDIMM
- 1 x Intel® I226 series 10/100/1000/2500Mbps GbE
- Multiple Expansion: Up to 79 PCIe Lanes
- Rich I/O: 4 USB 3.2, 4 USB 2.0, 2 SATA 3.0
System
- Processor
- AMD EPYC™ 8004 Processors AMD EPYC™ 8534P (64 cores, up to 3.1GHz, 128MB cache, 200W) AMD EPYC™ 8324P (32 cores, up to 3.0GHz, 128MB cache, 180W) AMD EPYC™ 8124P (16 cores, up to 3.0GHz, 64MB cache, 125W)
- Memory
- 6 channels DDR5-4800 RDIMM up to 576GB (ECC or non-ECC)
Expansion
- Interface
- 4 x PCIex16, 64 Lanes (Gen 5) + 1 x PCIe x8, 8 Lanes (Gen 5) 6 x PCIex1, 6 Lanes (Gen 3) 1 x PCIex1, Gen3 for BMC 1 x eSPI 2 x I2C 1 x SPI 2 x UART(TX/RX) 1 x SMBus 2 x SmartFAN
Ethernet
- PHY
- 1 x Intel® I226 series 10/100/1000/2500Mbps GbE
I/O
- SATA
- 2 x SATA 3.0 (up to 6Gb/s)
- GPIO
- 12 x GPIO
- Up Side
- 4 x USB 3.2 Gen 2x1 4 x USB 2.0
Watchdog Timer
- Output & Interval
- System Reset, Programmable via Software from 1 to 255 Seconds
Security
- TPM
- TPM 2.0
Power
- Type
- ATX: Vin, VSB, VCC_RTC AT: Vin, VCC_RTC Vin: 12V(+/-5%),VSB: 5V(+/-5%)
- Consumption
- TBD
OS Support
- Microsoft
- Windows Server 2024
- Linux
- Ubuntu
Environment
- Temperature
- Operating: 0 to 50°C Storage: -40 to 80°C
- Humidity
- Operating: 5 to 90% RH Storage: 5 to 90% RH
- MTBF
- TBD
Mechanism
- Dimensions
- COM HPC® Server Size E 160mm (6.30") x 200mm (7.87")
- Compliance
- PICMG COM HPC® R1.2, Server Size E
Standards and Certifications
- Certifications
- CE, FCC Class B, RoHS
Country of Origin
- Country of Origin
- Taiwan
